· Clear Vertical Cut Lens: For enhanced illumination over a wide perspective.
· FB type: Built-in audible alarm with 90dB at 1m.
· Installation: Vertical and horizontal.
· Body Color: Chrome plated.
· Lens: Superior impact and heat resistant polycarbonate resin for superior durability and light transmission.
· NPN/PNP Compatible: Direct connection to PLC (24V DC ONLY)
· Lighting Pattern: Flashing and Continuous.
· Dust-proof and waterproof IP65 (except for FB type: IP54).
· Available Colors: Red, Amber, Green, Blue, Clear/White.
|DIMENSIONS||- 37.5mm profile|
|RATED VOLTAGE||- 24V AC/DC|
|FUNCTIONS||- Continuous Only
- Continuous, Alarms
|MOUNTING||- Wall Mount|
|BODY STYLE||- Pre-assembled, pre-wired|
|BODY COLOR||- Body: Chrome Plated|
|STACKABLE TIERS||- Available from 3 to 5 tier versions|
|MODULE COLORS||- Red
|AUDIBLE STYLE||- Alarm 1: Selectable, single-tone, intermittent (fast beep) alarm; 90dB (at 1m)
- Alarm 2: Selectable, single tone, intermittent (slow beep) alarm; 90dB (at 1m)
|CONFORMITY STANDARDS||- UL Listed (E215660)|
|PROTECTION RATINGS||- IP65 (except for FB type: IP54)|
