FV-127JP 最多可有127個頻道。 非常適合安裝在需要多種聲音提示或是需要現場編輯的各種設備中。

  • 功率控制
  • MP3播放器
  • MP3語音
  • 105dB
  • MP3多頻道播放器 FV-127JP


  • MP3格式可以做到以高音質長時間播放。
  • 可存約長達8分鐘的MP3音樂。
  • 當使用SD卡(SD-2GP)時,播放時間可達240分鐘。
  • MP3可以使用播放列表編輯器2和選配SD卡(SD-2GP)輕鬆重新編輯和覆寫。 此外,儲存在設備中的MP3數據也可以轉存至SD 卡。
  • 可以通過外部訊號輸入進行3階音量調整(-10dB, -20dB, -30dB)。
  • 5種高音質播放模式。
  • 可以選擇輸入讀取時間。 (10msec或50msec)
  • 延長輸入負載的持續時間可增強減音能力。
  • 通過設定,可根據使用環境採取減音功能。
  • 端子台可為您提供安全可靠的接線方式選擇。
  • 選購品播放器(2W或4W可選擇)、AUX輸出和 BUSY輸出。
  • 額定電壓:DC 24V(工作電壓範圍:DC 19~29V)


額定電壓 DC 24V
輸入格式 MP3
內存容量 MP3:127的頻道,總計約480秒
頻道選擇 指撥開關設置也可選擇二進制
認證 RoHS
MPEG Layer-3 音訊編碼技術獲得Fraunhofer IIS 和 Thompson Licensing 認證
選購品 SPB-2E-W
